改性PBT
栏目：改性工程塑料 发布时间：2021-05-31 09:11
产品特征：符合ROHS标准、高机械强度、高刚性、高耐温性、电器性能好、尺寸稳定、不喷霜、外观优良、适用于精密器械成型。...
 改性PBT Modified PBT 产品应用：家电、灯具；电子产品内部制件、元器件；车用配件、电子继电器、连接器等注塑成型制件 改性特征：增强、阻燃/增强 产品特征：符合ROHS标准、高机械强度、高刚性、高耐温性、电器性能好、尺寸稳定、不喷霜、外观优良、适用于精密器械成型 |
|||||
|
Applications：Home appliance parts, lighting fixtures, internal parts of electronic products, electron component, car handle, door bolt, coil framework, relay of electric appliance, and connector injection molding products Modified Features: Reinforced, flame retardant/reinforced Product Features: Comply with ROHS, high mechanical strength, high rigidity, and high temperature tolerance, good performance of electric appliance, stable size, and bloom free, good appearance applicable to the precision shaping |
|||||
| 测试项目与标准Test Items & Standards |
增强型号 Reinforced |
增强/阻燃型号 Reinforced/Flame Retardant |
|||
| 项目Items | 测试标准Standard |
测试条件 Test Condition |
国际单位 S.I. Units |
PBT-30GF | FRPBT-30GF |
| 机械性能 Mechanical Properties | |||||
| 拉伸强度Tensile Strength | ASTM D638 | 10mm/min | MPa | 130 | 110 |
| 伸长率 Elongation | ASTM D638 | 10mm/min | % | 2.5 | 2.6 |
| 弯曲强度 Flexural Strength | ASTM D790 | 2mm/min | MPa | 180 | 145 |
| 弯曲模量Flexural Modulus | ASTM D790 | 2mm/min | MPa | 7500 | 6000 |
|
悬臂梁缺口冲击强度 Impact Strength, Izod notched |
ASTM D256 | 3.2mm,23℃ | J/m | 100 | 90 |
| 洛氏硬度 Rockwell Hardness | ASTM D785 | R-Scale | - | 120 | 120 |
| 热性能 Thermal Properties | |||||
|
热变形温度 Heat Distortion Temp |
ASTM D648 | 0.45MPa,6.4mm | ℃ | 220 | 210 |
| 1.8MPa,6.4mm | 210 | 220 | |||
| 电性能 Electrical Properties | |||||
| 体积电阻率Volume Resistivity | ASTM D257 | - | Ω.cm | 1016 | 1016 |
| 其他 Others | |||||
| 玻纤含量Glass Fiber | -- | -- | % | 30 | 30 |
| 比重Specific Gravity | ASTM D792 | 23℃ | g/cm3 | 1.53 | 1.63 |
| 收缩率Mold Shrinkage | ASTM D955 | 23℃ | % | 0.3/0.9 | 0.3/0.9 |
| 吸水率Weather Resistant | ASTM D570 | 23℃，24h | % | 0.06 | 0.07 |
| 阻燃性Flammability | UL94 | 1.6mm | class | HB | V-0 |
| 3.2mm | HB | V-0 | |||
| 建议加工工艺 Suggesting processing technology | |||||
| 熔体温度Melt Temp | ℃ | 235-255 | 240-260 | ||
| 料筒温度Barrel Zone Temp | ℃ | 220-270 | 220-260 | ||
| 模具温度Mold Temp | ℃ | 50-80 | 50-70 | ||
| 预干燥Pre-Dry Requirements |
120-140℃ 4-6hr |
120-140℃ 4-6hr |
|||
| 注：以上数值是根据实验室标准测定的代表数值，仅供客户参考，不作为质保承诺。 | |||||
| Note: The above data is based on standard laboratory condition, for reference only, not for product warranty. | |||||
